3 Phase Extreme Duty Planer
Product Code : EDS-LGI-15722
Eduscope India is a leading 3 Phase Extreme Duty Planer
Description:
The 3-Phase Industrial Planer features a 6-row spiral cutter head with 162 indexable carbide inserts.
The variable-speed feed rate of 20 to 40 feet per minute means you can get the best possible finish.
It has motorized table elevation and the bed rollers are power-driven and adjustable for height when milling rough-cut lumber.
The built-in chip deflector leads directly into the dust hood with a 5" dust port to help ensure the work area stays as clear as possible.
Specifications:
• Cutter head motor: 10 HP, 220V, 3-phase, 25A
• Table elevation motor: 1/2 HP
• Maximum stock width: 24"
• Maximum stock thickness: 9"
• Minimum stock thickness: 1/4"
• Minimum stock length: 10-1/2"
• Maximum cutting depth full width: 1/16"
• Maximum cutting depth 6" wide board: 3/16"
• Cutter head diameter: 4-5/8"
• Cutter head type: 6-row spiral with 162 inserts
• Insert size, type: 14 x 14 x 2mm, indexable carbide
• Cutter head speed: 5000 RPM
• Feed rate: Variable, 20–40 FPM
• Table size: 24" x 35-1/2"
• Dust port size: 5"
• Footprint: 30" x 40-1/2"
• Overall dimensions: 42-3/8" W x 36" D x 58" H
• Approximate shipping weight: 1980 lbs.
Features:
• Motorized table elevation with micro-adjust handwheel
• Variable-speed feed
• Twin V-belt drive (cutter head), chain drive (feed & elevation)
• Massive 6" thick precision-ground cast-iron table with bed rollers
• Segmented chip breaker and feed rollers
• Convenient control panel with magnetic switch protection
• Table height lock
• Inch and metric measuring scale
