Binocular Microscope
Product Code : EL-BLE-14776
Eduscope India is a leading Binocular Microscope
Quick Answer: Binocular Microscope is a brightfield binocular microscope with a double-layer mechanical stage and white LED illumination for detailed classroom and laboratory work.
Technical Specifications
| Specification | Value |
|---|---|
| Objectives | 4x, 10x, 40x and 100x |
| Eyepieces | WF10X/18 |
| Head | binocular head inclined 30 degrees and rotatable 360 degrees |
| Nosepiece | quadruple revolving nosepiece |
| Illumination | white LED illumination with intensity control |
| Focusing | coaxial coarse/fine focusing mechanism graduated to 0.002mm |
| Stage size | approximately 125mm x 116mm |
| Stage X-Y range | approximately 76mm x 30mm |
| Condenser | Abbe N.A. 1.25 |
| Interpupillary adjustment | approximately 48mm to 75mm |
The Binocular Microscope is part of EduScope India's range of biology lab equipment supplied to schools, colleges and institutions.
Construction and Features
The microscope has 4x, 10x, 40x and 100x objectives, white LED illumination with intensity control, and a coaxial coarse/fine focusing mechanism graduated to 0.002mm with an upper stop to protect the specimen. The double-layer mechanical stage measures approximately 125mm x 116mm with an X-Y range of approximately 76mm x 30mm and vernier accuracy of 0.1mm. It has a quadruple revolving nosepiece, a binocular head inclined 30 degrees and rotatable 360 degrees, diopter adjustment, interpupillary adjustment of approximately 48mm to 75mm, WF10X/18 eyepieces, an Abbe N.A. 1.25 condenser, a 10x eyepiece reticule and a dust cover.
It is EduScope India's step-up binocular microscope India option above the entry-level Compound Light Microscopes and digital Microscope.
EduScope India also supplies Compound Light Microscopes, Microscope and Stereo Microscope for related laboratory work, alongside the full biology lab equipment range.
