Product Code : EDS-LE-12954
Eduscope India is a leading Centrifugal pump, diesel driven
Description :
Centrifugal pump, diesel driven, with a capacity of 30 m3/hr at 20 m Total Manometric Head.
The pumping set is used for pumping surface water, maximum suction lift 5 metres (potentially up to 7 metres on request), from shallow wells, rivers, lakes.
Technical Specifications :
Self-priming centrifugal pumping set, capacity 30 Cubic Metres per hour at around 2900 RPM, at 20 metre TMH (Total Manometric Head) for 1-m suction head.
Maximum suction lift 5 metres.
The pump set is supplied with following accessories :
1 x suction hose, semi-rigid, minimum 5 m.
1 x delivery hose, minimum 20 m.
1 x stainless steel strainer.
1 x non return valve.
1 x tool kit for installation, operation and maintenance.
1 x oil container, 4 litres, for diesel engine.
1 x spare parts kit for 2000 hours of normal operation, including various filters, seals and one injector.
