DC Compound Motor Lab
Product Code : EDS-ETE-15558
Eduscope India is a leading DC Compound Motor Lab
Description:
DC Compound Motor Lab is an exclusive training system designed for Electrical laboratories to demonstrate the operation of DC compound motor. Students can understand the fundamental operating principle of DC Compound Motor. This product includes various experiments such as No Load Test, Load Test and Operating Characteristics of DC Compound Motor. The training system includes terminals for 4 point starters and rheostat so that these can be connected externally to the control panel.
Features:
• Machine with mechanical loading arrangement
• Provided with Digital Tachometer
• Machine with Class “B” Insulation
• Heavy Duty Base/Channel
• Terminals provided to use the optional externally
• Brake-Drum/Pulley with heat suppression facility
• Designed by considering all the safety standards
• Diagrammatic representation for the ease of connections
• Exclusive and Compact Design
• Learning material CD
Technical Specifications:
• DC Power Supply
• Input Mains: 230V AC ±10%, 50Hz
• Fixed DC output: 200V
• Variable DC output: 0 -200V
• Machines Specifications (2 Nos.)
• Both the machines are flexibly coupled and mounted on “C” channel base
• DC Machine
• Type : Compound
• Rating : 1HP
(Also available with 2HP, 3HP & 5HP)
• Voltage Rating : 200V
• Speed : 1500 RPM (No Load)
• Insulation : Class ‘B’
• Loading Arrangement : Mechanical
• Brake Drum/Pulley : Aluminum Casted
• Analog Meters used
• DC Voltmeter (MC) : 300V (2 Nos.)
• DC Ammeter (MC) : 5A (2 Nos.), 2A
• Dimensions (mm):
W 600 x D 450 x H 600 (Control Panel)
W 335 x D 450 x H 560 (motor)
• Weight:
17kg (approx.) (Control Panel)
40kg (approx.) (Motor)
