Product Code : EL-LGI-14381
Eduscope India is a leading Digital Oscilloscope
Quick Answer: The Digital Oscilloscope is a 100MHz mixed-signal instrument with 4 analog channels and 16 digital channels, a 7-inch TFT LCD display, and up to 24Mpts memory depth, for viewing and analysing electrical waveforms.
As genuine electronic lab instruments India equipment, its combination of 4 analog and 16 digital channels lets students capture and correlate analog signals alongside digital bus activity on one screen, with bundled analysis software built into the unit and USB host/device, LAN and auxiliary trigger/pass-fail ports for connecting to a PC or other lab equipment.
Specification
Value
Bandwidth
100MHz
Channels
4 analog, 16 digital (mixed-signal)
Memory depth
Up to 12Mpts / 24Mpts
Display
7-inch TFT LCD, 800 x 480 pixels
Ports
USB host, USB device, LAN, Aux (trigger out/pass-fail)
