Infrared Dryers
Product Code : EL-AGE-15076
Eduscope India is a leading Infrared Dryers
Quick Answer: The Infrared Dryers unit is an infrared curing lamp system used to spot-dry automotive paint repairs.
Technical Specifications
| Specification | Value |
|---|---|
| Type | infrared curing lamp system |
| Power supply | 1 Ph, 230V, 50Hz |
| Lamps | 3 lamps |
| Distance sensor | automatic distance sensor |
| Display | LED display |
| Temperature range | 40-100°C |
| Curing area | 1200 x 1000 mm |
| Lamp type | 21-inch quartz halogen lamps |
| Overall size | 1000 x 750 x 1800 mm |
| Weight | 45 kg |
Features
Running on a 1 Ph, 230V, 50Hz supply with 3 lamps, the dryer includes an automatic distance sensor, an LED display and a temperature range of 40-100°C over a curing area of 1200 x 1000 mm. A hydraulic lifter and a 360-degree lamp turning radius give flexible positioning, using short-wave technology through 21-inch quartz halogen lamps, at an overall size of 1000 x 750 x 1800 mm and a weight of 45 kg.
As a lab equipment manufacturer in India, EduScope India (Jainco) also supplies automotive garage equipment such as this infrared dryer to bodyshops, alongside its wider automotive garage equipment range.
It pairs naturally with EduScope India's Paint Booth and Prep Station, from the same paint-shop equipment range.
