Photogate System, Steel Ball, Release and Catch, Electronic Timer
Product Code : EL-PLE-15738
Eduscope India is a leading Photogate System, Steel Ball, Release and Catch, Electronic Timer
Quick Answer: The Photogate System, Steel Ball, Release and Catch, Electronic Timer is a precision free-fall gravity experiment kit that gives schools and colleges dependable physics lab equipment India for measuring the acceleration due to gravity ('g') with millisecond accuracy — a well-built, export-ready choice for institutions upgrading their laboratory equipment school India wide.
Construction and Specifications
The system uses an electromagnetic ball release mechanism coordinated with the electronic timer, so the steel ball begins its drop at the exact instant timing starts, ensuring an accurate free-fall reading. Two photogates, each with a red LED light indicator, are clamped to the aluminium frame pole ruler at the positions required for the experiment. The frame sits on a height adjuster with a height of 1200mm and an adjustable tripod base, and a vertical adjustment strap with plumline is used to align the frame perfectly vertical before each trial. The photogates connect to the electronic timer through a cable fitted with USB and RJ11 ends. The electronic timer (e.g. SMART Timer Big Display or equivalent) delivers an accuracy of 0.001 seconds, with a minimum size of 250mm x 145mm x 110mm and a mass of 0.8kg. The kit is supplied with steel balls of 10mm and 18mm diameter, along with a steel ball catcher bag to catch the balls after each drop, and the complete kit has a minimum size of 250mm x 225mm x 1290mm. Also included is a worksheet for determining and calculating 'g', teacher sample data for different photogate distances explaining the calculation, and a user manual, backed by a one-year supplier warranty.
Technical Specifications
| Ball Release | Electromagnetic release, synced with electronic timer |
| Photogates | Two, each with red LED indicator |
| Frame | Aluminium pole ruler on height adjuster, 1200mm, adjustable tripod base |
| Alignment | Vertical adjustment strap with plumline |
| Connectivity | Cable with USB and RJ11 ends |
| Timer Accuracy | 0.001 seconds |
| Timer Size / Mass | 250mm x 145mm x 110mm (min); 0.8kg |
| Steel Balls Supplied | 10mm and 18mm diameter, with catcher bag |
| Kit Size | 250mm x 225mm x 1290mm (min) |
| Included | 'g' worksheet, teacher sample data, user manual |
| Warranty | 1 year (supplier) |
As a manufacturer and exporter of physics lab equipment India wide, we regularly supply this Photogate System and other mechanics-lab instruments to schools, colleges and universities across the Middle East and GCC region, including Saudi Arabia, the UAE, Qatar and Oman, with export packaging and shipping documentation handled end-to-end.
We also support bulk and institutional orders for the Photogate System, Steel Ball, Release and Catch, Electronic Timer, working with school chains, university physics departments, CSR-funded lab-upgrade programmes and government tenders that require dependable laboratory equipment school India wide at scale, with consistent quality and reliable after-sales support.
Related Instruments
Pair the Photogate System, Steel Ball, Release and Catch, Electronic Timer with related timing instruments from our Physics Lab Equipment range, including the Timer with Two Photogates and the Spark Timer, both useful for motion and free-fall timing experiments.
