Table Saw
Product Code : EDS-LGI-15724
Eduscope India is a leading Table Saw
Description:
It is a floor circular saw with a cast iron worktable.
The base of the machine is a powerful cast worktable, to which is attached a sawing module made of the same material, which contains the drive of the blade and the mechanisms for its tilting and dipping.
Thick sheet steel extensions are attached to the table on the left and right, as well as guide components with millimeter markings. They additionally fasten the sections of the work surface and serve as a base for a parallel stop.
It is equipped with a convenient eccentric clamp with double-sided fixation and provides quick, convenient and rigid adjustment of the width of the rubber.
It can be installed both to the left and to the right of the blade, and can also be removed altogether (there are brackets on the body for storage).
For trimming and sawing at an angle, there is a transport stop that slides in a T-shaped groove (they are on both sides of the blade).
Features:
• Shaft locking mechanism for easy saw blade replacement
• Adjusting the saw blade inclination
• Adjusting the cutting depth
• Removable stop-blocker against back ejection of the workpiece
• Cast iron sawing module
• Cast iron workbench
• Removable sheet steel work table extensions on the left and right
• Adjustable parallel stop with eccentric clamp
• Movable angle stop with guide along T-slot
• Four retractable wheels for transportation with pedal-operated lifting mechanism
Technical Specification:
• High-voltage: 400 V
• Power consumption (output): 2.2 (1.8) kW
• Saw blade speed at idle: 4200 rpm
• Outer (seating) diameter of the saw blade: 254 (15.88 and 30) mm
• Dado disc outer (seating) diameter: 200 (15.88) mm
• Saw blade inclination angle: 0-45°
• Maximum cutting depth at 0° and 45° angles: 80 and 55 mm
• Desktop dimensions (LxW): 685x512 mm
• Extend desktop to the right (LxW): 685x250 mm
• Desktop extension on the left (LxW): 685x250 mm
• Maximum workpiece width when sawing with the rip fence on the right: 762 mm
• Exhaust connection diameter: 100 mm
• Length: 1440 mm
• Width: 1000 mm
• Height: 1050 mm
• Mass: 120
