Wheelchair
Product Code : EDS-LE-12943
Eduscope India is a leading Wheelchair
Description :
Wheelchair, manual assistant-controlled : Transport wheelchair.
Function and environment : Standard wheelbase and overall length. For intermittent or short-term transport in healthcare facilities.
Technical Specifications :
Overall length :
Maximum 1080 mm
Size and dimensions :
Seat width : 500 mm
Seat depth : at least 425 mm
Backrest height : at least 430 mm
Frame and seating system :
Folding frame
Push handles, integrated with back post, non-slip, ergonomic grip
Seat-to-back support angle: Not adjustable, 90 degrees with bend in back post in lower thoracic area
Back support upholstery : sling
Seat angle : 3 degrees
Seat upholstery : sling
Rear wheel position safe. In line with back post attachment to seat
Integrated tipping lever in frame for assistant to tip wheelchair to lift front castors to clear obstacles
Arm supports :
Removable arm supports
Arm support pad : Approximately 70% of seat depth.
Arm support design to protect clothing and cushion from rear wheels, dust, mud, etc.
Fixed height arm support : at least 240 mm high
Foot supports :
Seat to lower leg support angle : at least 109 degrees
Two individual flip-up and swing-away foot supports
Height adjustable range : at least 330-410 mm
Rear wheels and parking brakes :
Two small/medium rear wheels :
Diameter x width: 400 x 25 mm OR 305 x 45 mm depending on model selected
Puncture-proof rear tyres, solid polyurethane tyres
Rear wheels parking brakes, frame mounted, push-pull type.
Fixed axles
Front castors :
Two large diameter castors
Diameter x width: 200 x 50 OR 32 mm depending on model selected
Puncture-proof, solid polyurethane castor wheels
