Product Code : EL-LGI-15714
Eduscope India is a leading DC Servo Motar Board
Quick Answer: The DC Servo Motor Board is a versatile control-systems demonstration board that teaches motor servo-control fundamentals, letting students configure the system to control motor position and speed.
As genuine engineering lab equipment India apparatus, it guides students through experimentally modelling a DC motor and then designing and implementing proportional-integral (PI), proportional-derivative (PD) and full proportional-integral-derivative (PID) controllers for speed control, position control, and tracking-error/disturbance rejection respectively.
Specification
Value
Type
DC servo motor control demonstration board
Configurable control
Motor position control and speed control
Learning objective 1
Experimental modelling of a DC motor
Learning objective 2
PI controller design for motor speed control
Learning objective 3
PD controller design for motor position control
Learning objective 4
PID controller design for tracking error and disturbance rejection
