Transient Analysis oF RC-RL Circuits Experiments
Product Code : EDS-LGI-15680
Eduscope India is a leading Transient Analysis oF RC-RL Circuits Experiments
Description:
It has been designed specifically for the Transient Response Analysis with both DC and AC signals as input.
This is useful for students to study and analyze the behavior of any circuit during the transient period.
The study of transient and steady state response of a circuit is very important as they form the building block of most electrical circuits.
With this product, we can easily calculate time constant of RC and RL circuits theoretically and practically.
Experiments:
• Study the Transient Response of a series RC circuit and Understand the time constant concept with DC power supply
• Study the Transient Response of a series RL circuit and Understand the time constant concept with DC power supply
• Study of Transient Response of RC/RL circuit with signal generator
Setup Includes:
Experiment Trainer Board that Contains:-
• Power Supply : 5 V DC
• Signal Generator : 100 Hz
• Various test point
