Filtration, Microanalysis Vacuum Filter Holder Set, 25mm with Stainless Filter Support
Product Code : EL-LGI-13274
Eduscope India is a leading Filtration, Microanalysis Vacuum Filter Holder Set, 25mm with Stainless Filter Support
Quick Answer: the Filtration, Microanalysis Vacuum Filter Holder Set, 25mm with Stainless Filter Support is a small-volume membrane filtration unit India labs use for particulate or biological contamination analysis, built around a 25mm filter diameter and 2.5cm² filtration area rather than the larger funnel sizes used for bulk sample filtration.
This chemistry lab equipment India set includes a borosilicate glass funnel and base, a removable stainless steel screen filter support, an anodized aluminum spring clamp, and a No. 5 perforated silicone stopper that mounts directly into a standard 125ml filtering flask. The 15ml funnel is not compatible with thick prefilters or laminated filters, which won't seal properly in this holder, and the unit should not be autoclaved with membrane filters still installed; unlaminated PTFE or PVDF membranes are recommended for solvent work.
| Specification | Value |
|---|---|
| Filter diameter | 25mm |
| Filtration area | 2.5cm² |
| Funnel capacity | 15ml |
| Materials | Borosilicate glass funnel/base, stainless steel screen support, anodized aluminum clamp, silicone stopper |
| Outlet fitting | No. 5 perforated silicone stopper (fits 125ml filtering flask) |
| Overall dimensions | 15.2cm height, 2.5cm diameter |
| Recommended membranes | Unlaminated PTFE or PVDF for solvent use |
| Limitations | Not compatible with thick/laminated filters; not autoclavable with membrane installed |
EduScope India also equips public-health and water-testing laboratories with small-volume filtration sets like this one in bulk, so contamination-screening programs can standardize on the same 25mm holder across every testing site.
A smaller-volume counterpart to our All-Glass Filter Holder, sized for microanalysis rather than bulk sample filtration. See more of our Lab General Instruments range.
Request a Quote: Contact EduScope India for pricing, lead times and bulk-order terms on the Filtration, Microanalysis Vacuum Filter Holder Set, 25mm with Stainless Filter Support — get in touch here.
