Transistor Application Trainer
Product Code : EDS-ETE-15516
Eduscope India is a leading Transistor Application Trainer
Description:
Covers the basic applications of transistors such as BJT, FET, MOSFET, and UJT etc.
On-board resources such as Resistor, Capacitor, Inductor, Diode and Potentiometer banks of different values are provided
On-board regulated variable and isolated power supplies
Experiments
To identify and check type of Transistor NPN, PNP
BJT as Switch
Amplifier
Logic gates using BJT
BJT as a DC amplifier
CE amplifier-frequency response, signal handling capacity, input and output impedance
Cascade amplifier-frequency response, signal handling capacity, input and output impedance
Feedback amplifier
Voltage series feedback (negative) amplitude, frequency response, input and output impedance calculation
Class-A / Class-B power amplifier
Regulator
Series and shunt regulator, calculate ripple factor
