Signal Generator
Product Code : EL-PLE-14994
Eduscope India is a leading Signal Generator
The Signal Generator from Eduscope India is an audio frequency function generator built for physics and electronics laboratories, producing stable triangular and square waveforms for teaching waveform, frequency, and oscillation concepts, part of our range of Physics Lab Equipment for classroom and practical work. Quick Answer: this generator covers 1Hz to 100kHz across five decade ranges, with output amplitude adjustable 0-10V and a rated output of 0-3.5Vrms (10V peak-to-peak) - electronic lab instruments India labs use for waveform and oscillation teaching alongside an oscilloscope.
Construction and Specifications
The Signal Generator covers a frequency range of 1Hz to 100kHz, spread across five decade ranges, allowing precise selection for a wide variety of experiments. Output amplitude can be adjusted from 0 to 10V, giving flexibility to match the signal levels required for different laboratory setups. Triangular and square waveforms are selected through a push switch with LED indication, making the choice of waveform quick and visible during use. The output signal is rated at 0-3.5Vrms (10V peak to peak) on open circuit, and is continuously adjustable through an uncalibrated amplitude control knob. Fine control of the output is achieved through a combination of the frequency multiplier and set frequency dial, keeping distortion at a low level across the operating range. The unit is switched on through a mains rocker switch with indicator light, and is built into a compact enclosure measuring 200 x 150 x 100mm - reliable physics lab equipment India electronics departments use for signal and waveform teaching.
Technical Specifications
| Parameter | Specification |
|---|---|
| Frequency Range | 1Hz - 100kHz, 5 decade ranges |
| Output Amplitude | 0-10V, continuously adjustable |
| Output Signal | 0-3.5Vrms (10V peak-to-peak), open circuit |
| Waveforms | Triangular and square, push switch with LED indication |
| Enclosure | 200 x 150 x 100mm |
Related Instruments
This generator pairs well with our Oscilloscope and Digital Multimeter for waveform observation and circuit measurement in the same lab session.
Eduscope India regularly exports the Signal Generator and related electronics apparatus to schools, colleges, and universities across Kenya, Tanzania, Uganda, and Rwanda, with careful export packing and complete documentation for every consignment.
We also support bulk buyers - school chains, CSR-funded science lab programs, and education distributors - who need multiple units for classroom use, with tender-ready specifications and volume pricing available on request.
Request a Quote
Schools, colleges, universities, and laboratory suppliers looking to add the Signal Generator to their physics curriculum or export order can Contact Us for pricing, bulk-order support, and shipment documentation.
